To prevent CloudCompare from filling holes automatically when creating a mesh from a point cloud, you typically need to adjust the parameters or settings in the mesh generation process


I attached here pointscloud example with a small hole in its top, I can not adjust the parameters to generate ...

If I cancel meshing by Poisssonrecon , it appears again showing "reconstruction in progress"

In many cases, adjusting the parameters or settings in the mesh generation process does not help

for example, can we generate a mesh with a side hole in the attached pc example

If you can not manage by using "Density' output", You can use segment tools to open a hole in the mesh.
Also, You can edit in Blender 3D software

Can we work on this example?



then Tools--> Distances
then result in SF

Take care !!
2.5d volume has limitations
Please check the attached example where 2.5d volume fails because 2 z levels in the same pointscloud
real volume=2.964 cubic units

Most of the time, but not all the cases, optimum volume and area is when % of matching cells is close to % of shape area to area of containing rectangular (min x min y, max x max y)
and it is tricky
You can use try and error or visual inspection
Usually, you start with samll grid and increase till ...

To find real 3d shaped area ,you can mesh it and then use measure surface
edit -->mesh-->measure surface

yes, it is a projected area, not 3d shaped area
check attached example

check xyz order during import
